In modern electronic devices, high-speed differential signal routing is one of the key challenges in PCB (Printed Circuit Board) design. This article explains the importance of high-speed differential signaling and best practices in PCB design.
1. The importance of high-speed differential signals
l Data transmission speed: High-speed data transmission usually uses high-speed differential signals, such as USB, HDMI, PCIe, etc., which have extremely high requirements for signal integrity and stability.
l Anti-interference ability: Differential signals have strong anti-interference ability, which can reduce the impact of electromagnetic noise and improve signal quality.

2. Best Practices
l Differential pair matching: The lengths of the two lines (positive and negative) of the differential signal must match to ensure that the signals reach the destination at the same time and avoid phase misalignment.
l Differential pair spacing: The spacing between differential pairs should be large enough to reduce crosstalk and mutual capacitance effects.
l Layer stacking of differential pairs: Place differential pairs on the same layer to reduce signal transmission path length and delay.
l Ground pin: The ground pin of the differential signal should be as close as possible to the differential pair to reduce the loop area.
l Differential pair trace width: Consider signal speed and circuit board material, choose appropriate trace width to match differential impedance.
l Terminal impedance matching: Add appropriate impedance at the terminal, usually 100 ohms, to match the impedance of the differential signal.
l Differential signal simulation: Use simulation tools to verify the performance of differential signals to ensure that design requirements are met.
In summary, high-speed differential signal routing is crucial in PCB design, requiring special attention to signal integrity and transmission performance. By following best practices and using simulation tools, designers can ensure the reliability and stability of high-speed differential signals, thereby improving the performance of electronic devices.
